OUTSWING FIBERGLASS CASEMENT WINDOW

OUTSWING FIBERGLASS CASEMENT WINDOW

In comparison to steel or aluminum casement windows, pultruded fiberglass windows are structurally glazed which gives them a phenomenal strength. Stainless steel reinforcement bars make sections capable of spanning large distances.

DESIGN OVERVIEW

• Fiberglass is thermally efficient

• Windows material is resistant to any extreme weather conditions compared to steel, wood, or vinyl

• Pultruded fiberglass is pound-for-pound stronger than steel

• Continuous gasket system provides the highest resistance to air leakage

• Elegant traditional hardware

• Extruded 4"x4" brass butt hinges, solid cast bronze locking handles, strike plates, and friction stay bars

• Sash swings outward, and opening travel could be restricted by friction stay bar with the nut

• Frame depth 2.375"

• 1" insulating glass with a variety of options (Low-E, Laminated, Tempered, Obscure, etc.)

• Bronze or Clear Anodized spacer between the glass

• Available with surface-mounted and “between-the-glass” style muntin grids for a historic “small-pane” look

• Standard and custom panning to match landmark conditions

PERFORMANCE (AAMA/WDMA/CSA 101/I.S.2/A440-08)

• Performance class CW-PG60 (Design Pressure 60.15 psf)

• Air Infiltration 0.03 cfm/sq. ft

• More water resistant: water penetration resistance pressure 12.11 psf

• Better acoustical performance: STC 36, OITC 30 (glass combination: 1/4" Lami, 11/16" argon, 5/16" Lami)

• Thermally efficient: U-Factor 0.35

HARDWARE

Locking handles, strike plates and friction stay bars are available in standard Oil-rubbed Bronze,  Polished Chrome and Unlacquered Brass finishes. Custom finishes are also available.

FRAME FINISH OPTIONS

Fiberglass windows are available in single- and dual-color options:

• Variation of exterior and interior choices

•
